NVR724DR-256 NVR ( Network Video Recorder )

Description

NVR724DR-256 NVR (Network Video Recorder) is a high performance network video surveillance system for high-end, convenient, and reliable IP-based real-time monitoring and video recording. Powered by Dual-core embedded processor CPU, the Linux-embedded NVR supports 256 channel H.264 and M-JPEG recording from Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videosec, Vivotek and etc. IP-based security cameras. With high performance handle capacity, NVR724DR-256 NVR supports long-term and high performance megapixel recording (up to 2 megapixels) from various IP cameras anytime, anywhere over the web, independent of any PC. and smart mobile phone, iPhone, iPad, Adroid.

Powerful Features

Up to 256 channel with 1080P realtime live view
H.264/MJPEG dual codec decoding
Up to 2 megapixels resolution ip camera
Max 384 Mbps incoming bandwidth
1080P HDMI/VGA simultaneous video output
1 / 4 / 9 / 16 channel synchronous realtime playback, GRID interface
1 / 4 / 8 / 9 / 16 / 25 / 32 channel synchronous realtime preview, GRID interface
ONVIF Version 2.0 conformance
Support 16 SATA HDDs up to 64TB, 1 eSATA up to 24TB, 4 USB2.0
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & iPhone, iPad, Adroid(DMSS)

System Connection

PC CMS Software

Register up to 1000 channels connection and 64 live viewing at 1 screen, support max 121(11x11) view
Support DVRs, video servers, IP cameras, decoders and other network products connection.
PTZ, bidirectional talk, camera settings, color adjustment
Support device management, configuration, reboot and other operations
Support decoder connection to realize virtual matrix system and video wall display
Support different alarm types: external, motion detection, video loss, camera masking and etc.
Support video monitoring project, layout configuration, recording plan and etc.
Device status and other information provided in the "health report"
Support video search from local PC, device itself and other storage center
Used for the central monitoring system

Mobile Phone Surveillance Software


		iDMSS for ios System :	Support iPhone OS 4.1 or higher and iPad
		gDMSS for Android System :	Support Android OS 2.0 or higher.
		DMSS for Blackberry System :	Support Blackberry OS 4.6 or higher (Not support 7.0 OS).
		DMSS for Symbian System :	Support Symbian S60 3rd.
		DMSS for Window Mobile System :	Support Windows Mobile OS 5.0 or higher.
		DMSS for Windows System :	Support Windows Phone OS 7.0 or higher

Technical Specifications

NVR724DR-256
Main Processor	Dual-core embedded processor
Operating System	Embedded LINUX

Video & Audio
IP Camera Input	256 channel
Two-way Talk	1 channel Input, 1 channel Output

Display
Interface	1 HDMI, 1 VGA, 1TV
Resolution	1920x1080, 1280x1024, 1280x720, 1024x768
Display Split	1 / 4 / 8 / 9 / 16 / 25 / 32
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording

Recording
Compression	H.264 / MJPEG
Resolution	1080P(1920x1080) / 1.3M(1280x960)/ 720P(1280x720) / D1(704x576/704x480) & etc.
Record Rate	Max Mbps
Bit Rate	48~ 8192kbps
Record Mode	Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval	1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection & Alarm
Trigger Events	Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection	Motion Detection, MD Zones: 396(22x18), Video Loss & Camera Blank
Alarm Input	16 channel
Relay Output	6 channel

Playback & Backup
Sync Playback	1 / 4 / 9 / 16
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode	USB Device / Network

Network
Ethernet	4 RJ-45 port (10/100/1000Mbps)
Network Function	HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max. User Access	20 users
Smart Phone	iPhone, iPad, Android, Windows Phone

Storage
Internal HDD	16 SATA ports, up to 64TB, Raid (redundancy)
External HDD	1 eSATA port (Max 4 SATA HDDs), up to 16TB

Auxiliary Interface
USB	4 ports USB2.0
RS232	1 port, For PC communication & Keyboard
RS485	1 port, For PTZ control

General
Power Supply	AC 100V~240V, 50/60Hz
Power Consumption	200W (without HDD)
Working Environment	-10°C ~ +55°C / 10% ~ 90%RH / 86~106kpa
Dimension(WxDxH)	4U, 480(W)x494(D)x175(H)mm
Weight	29KG (without HDD)
